| MODEL/BASE SIZE |
XR871-90 |
XR871-110 |
XR851-90 |
XR851-110 |
| Working Width |
90' |
110' |
90' |
110' |
| Rows of Tines |
7 |
7 |
5 |
5 |
| Effective Tine Spacing |
1.43 " |
1.43 " |
2.4 " |
2.4 " |
| Harrow Sections |
10' wide, 7 bar sections |
10' wide, 7 bar sections |
10' wide, 5 bar sections |
10' wide, 5 bar sections |
| Transport Length |
68' 0" |
78' 0" |
68' 0" |
78' 0" |
| Transport Width |
14' 6" |
14' 6" |
14' 6" |
14' 6" |
| Transport Height |
14' 3" |
14' 5" |
14' 2" |
14' 4" |
| Mass |
23100 lb |
26400 lb |
22200 lb |
25300 lb |
Minimum Towing Vehicle Mass for
Transport (All Units) |
Implement Mass x 0.667 |
Implement Mass x 0.667 |
Implement Mass x 0.667 |
Implement Mass x 0.667 |
| Maximum Transport Mass (All Units) |
Empty Mass + 10000 lbs on hitch |
Empty Mass + 10000 lbs on hitch |
Empty Mass + 10000 lbs on hitch |
Empty Mass + 10000 lbs on hitch |
| Maximum Mass (All Units) |
Empty Mass + 10000 lbs on hitch |
Empty Mass + 10000 lbs on hitch |
Empty Mass + 10000 lbs on hitch |
Empty Mass + 10000 lbs on hitch |
| Hitch Capacity (All Units) |
Up to 10000 lbs for on-board granular application tank
(includes tank, frame and product) |
Up to 10000 lbs for on-board granular application tank
(includes tank, frame and product) |
Up to 10000 lbs for on-board granular application tank
(includes tank, frame and product) |
Up to 10000 lbs for on-board granular application tank
(includes tank, frame and product) |
| GENERAL SPECS (all sizes) |
XR871 |
XR851 |
| Tires |
| Main Frame - Standard |
500/60R22.5
Pressure - 27 psi |
500/60R22.5
Pressure - 27 psi |
Main Frame - With 5000 lb. Granular
Capacity on Hitch |
500/60R22.5
Pressure - 43 psi |
500/60R22.5
Pressure - 43 psi |
Main Frame - With 10000 lb.
Granular Capacity on Hitch |
500/60R22.5
Pressure - 58 psi |
500/60R22.5
Pressure - 58 psi |
| Wings - Standard |
500/60R22.5
Pressure - 27 psi |
500/60R22.5
Pressure - 27 psi |
| Standard |
| Boom Clearance |
Fixed 28" |
Fixed 28" |
| Main Boom Tubing |
12" x 12" x 0.25" wall |
12" x 12" x 0.25" wall |
| Safety Chain, SMV Sign & Lights |
Standard |
Standard |
| Wheel Hubs - Standard |
Triple-lip seals on 8000 lb hubs
Wheel Nut Torque - 160 ft lb |
Triple-lip seals on 8000 lb hubs
Wheel Nut Torque - 160 ft lb |
| # of Hydraulic Outlets Required |
Three - Standard |
Three - Standard |
| Latch Control |
Spring-loaded |
Spring-loaded |
| Tine Angle Control |
Standard - Hydraulic, Adjustable from 45° to 90° |
Standard - Hydraulic, Adjustable from 45° to 90° |
| Hydraulic Section Angle Control |
Standard |
Standard |
| ADF (Adjustable Down Force) Control |
In-Cab Control |
In-Cab Control |
*All weights & transport dimensions are estimates & are subject to change. Every effort has been made to ensure that the information is accurate/current at the time of production.
